Stop Soft Tubes from Slipping Off
Our barbed elbow fittings help you connect soft tubing while changing the direction of the pipeline. You simply screw them into place. They are made of carbon steel.
The barbed design holds the tube securely in place, preventing it from slipping off. The soft tube is pushed over the barbs and secured with a clamp. This makes installation simple and reliable.
We manufacture each part according to your drawings, ensuring consistent angles and barb dimensions for every piece. We supply these barbed elbow fittings to automotive manufacturers and have received a quality award from a major car maker in 2015.
Exact Sizes for a Secure Fit
The large diameter is 21.4 mm, and the small diameter is 14.5 mm. The width is 31 mm, and the height is 37 mm. Length and thickness are not fixed and can be customized according to your requirements.
Thread size is also customizable. The fittings use a screw connection. These barbed elbow fittings are produced in our factory in Yuhuan, China, a major automotive parts production base, allowing us to source raw materials efficiently.
We have 150 workers and 50 quality inspectors and have passed the automotive industry quality management system certification.
Strict Quality Control at Every Step
We use only high-quality steel. Upon arrival, all raw materials are inspected for chemical composition and dimensions. Any unqualified materials are returned immediately.
During production, operators conduct self-inspections, and quality inspectors perform hourly sampling checks. If any issue is detected, production is stopped immediately for correction.
Before packaging, every barbed elbow fitting is fully inspected, including appearance, dimensions, threading, and fit. Only approved products are packed and shipped. We maintain detailed quality records and continuously reduce our defect rate each month.
Product Parameter Table
|
Parameter |
Value / Spec |
|
Product Name |
Barbed Elbow Fitting |
|
Thread Size |
Customizable |
|
Big Diameter |
21.4 mm |
|
Small Diameter |
14.5 mm |
|
Length |
/ |
|
Width |
31 mm |
|
Height |
37 mm |
|
Thickness |
/ |
|
Connection Type |
Screw Connection |
|
Material |
Carbon Steel |
